Tannoy

Turnberry

Product Line: .
Product Type: .

 TURNBERRY

  • 2 Way Floorstanding 10" Dual Concentric HiFi Loudspeaker (Oiled Walnut)
  • Dual Concentric driver technology provides class-leading coherence and point-source imaging
  • 10" highly efficient driver with 93 dB/Watt sensitivity and 400 Watt peak power handling deliver breath-taking dynamics and realism
  • Tulip Waveguide with 33mm aluminium-magnesium dome enhances the point source symmetrical dispersion properties, providing exceptional high frequency clarity and articulation
  • Low frequency paper pulp cone with twin roll fabric surround provide natural sounding midrange and bass transient performance
  • Handcrafted oiled walnut veneered cabinet with walnut inlays provides a unique and timeless piece of furniture
  • capacitors, low loss laminated core inductors and close tolerance wirewound resistors delivering a more natural and cohesive sound
  • Custom gold plated bi-wireable binding posts to improve signal transmission and integrity
  • Fifth binding post provides grounding to reduce radio frequency interference and improve midrange clarity
  • High density particle board cabinet provides extreme rigidity to control low frequency performance
  • Distributed Port system gives powerful and extended low frequency performance
  • Extensive bracing incorporating DMT (Differential Materials Technology) to couple drivers to cabinets
  • Precision machined gold anodised aluminium adjustment panel metal trim complements the aesthetic of the real wood cabinet
  • Specially formulated Prestige wood wax provided to keep cabinet in pristine condition
  • Tannoy - 90 years of British sound heritage and innovation
  • 10-Year Warranty Program*
  • Designed and manufactured in the U.K.

Specifications

PERFORMANCE

Recommended amplifier power   20 - 200 Watts
Continuous power handling   100 Watts RMS
Frequency response   34Hz - 44kHz -6dB
Sensitivity   93dB (2.83 Volts @1 metre)
Nominal impedance   8 Ohms (Min 5 Ohms)

DRIVE UNITS

Dual Concentric high-frequency   33mm (1.30") aluminium alloy dome with Tulip Waveguide
Dual Concentric low-frequency   254mm (10.00") treated paper pulp cone with HE twin roll fabric surround. 52mm (2.00) edge wound voice coil
Dispersion   90 degrees conical

CROSSOVER

Frequency   1.3kHz
Type   Bi-wired, hard-wired passive, low loss 2nd order low pass, 2nd order high pass
Adjustment   +/- 3dB over 1.3kHz to 44kHz shelving

CONSTRUCTION

Enclosure type   Dual Distributed Port
Volume   100L (3.5 cu.ft)
Dimensions   950 x 456 x 336mm (37.5" x 18" x 13.25")
Weight   30kg (66 lbs)
Finish   Walnut veneer with solid walnut trim and edging. Internally cross braced and heavily damped.
